MAX 110V Submersible Puddle Pump (530W) – Drains to 1mm – 2" Outlet

Product Name

MAX 110V Submersible Puddle Pump (530W) – Drains to 1mm – 2" Outlet

Overview

The MAX 110V Submersible Puddle Pump (530W) is a compact and powerful solution for removing standing water from construction sites, basements, trenches, and excavations. Designed to drain water down to just 1mm, it features a specially engineered bottom plate for near-dry pumping performance. The pump is fitted with an integral float switch for automatic operation and is suitable for pumping water containing solids up to 6mm. With an IP68 rating and thermal overload protection, it is built for reliable performance in demanding site conditions. :contentReference[oaicite:2]{index=2}

Key Features & Benefits

• Drains water down to 1mm for effective puddle and residual water removal.
• 530W motor delivers up to 250 L/min pumping capacity.
• Integrated float switch enables automatic on and off operation.
• Submersible design suitable for temporary and permanent installations.
• Handles solids up to 6mm for site and general water applications.
• IP68 rated housing supports use in fully submerged conditions.
• Thermal overload protection helps protect the motor during extended use.

Installation & Applications

Suitable for dewatering basements, foundations, trenches, lift shafts, and flooded areas on construction and industrial sites. Connect to a suitable 110V power supply via an RCD. Position the pump on a flat surface to achieve minimum drain-down levels and ensure the outlet hose is securely connected.

Who Is This For?

• Construction teams managing site water and flooding.
• Groundworkers requiring fast puddle and trench drainage.
• Facilities and maintenance teams handling water ingress.
• Procurement teams specifying 110V compliant site pumps.

Competitive Advantages

Unlike standard submersible pumps, this model is specifically engineered to drain water down to 1mm, reducing manual clean-up time on site. The combination of compact size, automatic float switch operation, and IP68 protection makes it a dependable choice for professional users requiring efficient site drainage.

Why CMT?

CMT Group supplies reliable site equipment and water management solutions from trusted brands such as MAX, helping professionals source compliant, performance-led tools.

• UK trade supplier for construction and industrial pumping equipment.
• Clear specifications to support compliance-led purchasing.
• Consistent availability for site and project requirements.

Frequently Asked Questions

What does “drains to 1mm” mean? It means the pump can remove water until only a 1mm residue remains, reducing the need for manual clean-up.

Can this pump handle dirty water? Yes. It can pump water containing solid particles up to 6mm in size.

Is the pump suitable for continuous operation? The pump includes thermal overload protection to help prevent damage during extended use.

Does it require a specific power supply? Yes. It operates on a 110V AC 50Hz supply and should be connected via an RCD.

Specifications Table

Product Name	MAX 110V Submersible Puddle Pump (530W) – Drains to 1mm – 2" Outlet
Product Code	PL080003
Voltage	110V AC 50Hz
Rated Input	530W
Max Output	250 L/min
Max Head Height	11m
Outlet Size	2in (50mm)
IP Rating	IP68
Weight	13.5kg

Operating Instructions

Never allow the pump to operate if the water level has dropped below the minimum level required by the product as it may cause damage. Ensure the pump is prepared and positioned correctly before connecting it to main power.

Switching the Pump On and Off

• Connect the pump to a mains supply via an RCD and switch it on.
• The integral float switch will turn the pump off when water drops below a certain level. At this point, disconnect from mains power.
• Some models may run continuously once powered on, ignoring the float switch. Switch off manually when needed.
• A thermal overload feature stops the pump if it overheats. Disconnect from power, let it cool (approx. 20 mins), and investigate the cause. Reconnect once resolved.
• If it doesn’t restart automatically, disconnect and troubleshoot.

Pumping Distance and Volume

• Maximum horizontal distance and flow rate are affected by head height.
• Head refers to the vertical height between the water surface and the highest point it is pumped to, regardless of hose length.
• As head height increases, both flow rate and pumping distance decrease.

Maintenance & Troubleshooting

Always ensure that the pump has completely stopped and is disconnected from main power before attempting any product care. Technical maintenance and servicing may only be performed by qualified personnel.

General Care and Storage

• Periodically flush with clean water, especially after long periods of inactivity or extended use in water.
• Check and clean the impeller housing regularly to remove debris.
• If used in debris-heavy water, rinse thoroughly after each use.
• Wipe the pump exterior with a dry or damp cloth only. Avoid solvents or harsh chemicals.
• Ensure the pump is completely dry before storing.
• Store away from direct sunlight, frost, and out of children’s reach.
• For permanent installations, run the pump weekly to prevent motor issues.

CAUTION: Never let water inside the pump freeze. This can cause permanent damage.
